| Model | Max.Blank Diameter/mm | Max.Blank Length/mm | Strike | Capacity/pcs/min | RPM(PCS/min) | Cut-off Die diameter(mm) | Punch Die(1st)(mm) | Punch Die(2st)(mm) | Cutter Size/mm | Main Motor Power/kw | Volume (L*W*H)/m)Weight/kg | Weight/kg |
| DL4-20A | φ5.0 | 20 | 68 | 80-120 | φ32×105 | φ15×30 | φ25×65 | φ25×65 | 9×30×70 | 6级-1.5kw | 2.10×1.02×1.05 | 1300 |
| DL5-30A | φ8.0 | 30 | 102 | 80-100 |
φ34.5×130 |
φ19×35 | φ31×75 | φ31×75 | 9×30×72 | 6级-2.2kw | 2.50×1.13×1.18 | 1700 |
| DL5-40A | φ8.0 | 40 | 102 | 80-100 | φ34.5×145 | φ19×35 | φ31×75 | φ31×75 | 9×30×72 | 6级-2.2kw | 2.50×1.13×1.18 | 1750 |
