1. The thread rolling machine is used for processing non-standard parts and forming various ordinary screw threads.
2. Improve the company's production efficiency for difficult screw products and hardware products.
3. This product is the best machine for producing difficult screws in the screw industry.
| Model | Max.B lank Diameter/mm |
Max.B lank Length/mm |
Moving Dies Stationary Length/mm |
Capacity /pcs/min |
Main Motor Power/kw |
Volume (L*W*H)/m |
Weight/kg | |
| R3-20Z | 3 | 20 | 55×18×20 | 45×18×20 | 330-380 | 4级-0.75KW | 1.30×0.98×1.30 | 250 |
| R4-25Z | 4 | 25 | 80×20×25 | 65×20×25 | 280-330 | 4级-2.2KW | 1.57×1.05×1.50 | 320 |
| R4-40Z | 5 | 40 | 89×25×40 | 76×25×40 | 260-300 | 6级-2.2kW | 1.60×1.44×1.55 | 850 |
| R5-50Z | 5 | 50 | 105×25×50 | 90×25×50 | 220-260 | 6级-3.0KW |   1.67×1.35×1.50 |
950 |
| R5-65Z | 6 | 65 | 105×25×65 | 90×25×65 | 120-140 | 4级-3.0KW | 1.70×1.36×1.50 | 1000 |
| R6-80Z | 8 | 80 | 125×25×80 | 110×25×80 | 80-100 | 4级-4.0KW | 1.75×1.52×1.50 | 1100 |
